◆ Combines video, power and data into  a  single RJ-45 4-pair cable
◆ Use with the power-video-data transceiver at the  camera
◆ 16 isolated camera power , 1 A max per channel
◆ Built-in passive transceivers with surge protection
◆ 60 dB cross talk and noise immunity
◆ Designed for structured wiring applications

Technical Specifications
◆Video Format NTSC, PAL, SECAM
◆Frequency DC to 8 MHz
◆Coax 75 Ohms
◆Twisted Pair 100 Ohms
◆CMRR 60 dB
◆Power fused at 1.5A max/CH.
◆Connectors Video: BNC
◆UTP: RJ-45
◆Power: Build-in AC90-240V to DC13V converter

Environmental
◆Humidity:0 to 95%, non-condensing
◆Temperature:Operating: -10°C to +70°C
◆Storage: -30°C to +70°C

Mechanical
◆PVD-64J&B :160X170X44 mm
